| Brand Name : | CN CABLE |
| Model Number : | Flat mining cable |
| Certification : | CE |
| Payment Terms : | L/C, T/T |
| Delivery Time : | 30days after payment |
Application
Applicable for connection of movable distribution devices and hoisting machineries
with rated voltage 6KV and 10KV.
The cable is suitable for heavy equipment such as port bucket turbines, port container cranes, port single-arm gantry cranes, port gantry cranes and other heavy equipment as power transmission lines, as well as various mobile devices.
Characteristics
The long-term allowable working temperature of the core is 85℃.
The maximum rated temperature of the cable conductor is 90℃.
When short-circuit (the longest duration does not exceed 5 seconds) the maximum temperature of the cable conductor does not exceed 250 ℃.
Allowable minimum ambient temperature for cables: UGEFP type: -15°C; UGEFHP type: -33°C.
The minimum allowable bending radius of the cable: 6D when used to fix equipment; 10D when connected in a freely movable manner; 12D when retracted with a cable reel; 15D when using a steering wheel (where D is the cable diameter).
Advantage
1. Rich production experience.
2. Strict quality control procedures
3. Product testing
4. Quality assurance and after-sales
We can produce according to the required standard.
Technical parameter
| Model | Cores×Nor. (mm2) | Conductor structure | Approx. overall diameter(mm) | 20℃ Phase Core Insulation Resistance ≤ (Ω/km) | kg/km Approx. weight(kg/km) | |
| Copper core | Tinned copper core | |||||
| GKFB-10KV | 3×16+3×16/3 | 126/0.04 | (70-75)×(31-33) | 1.21 | 1.24 | 3700 |
| 3×25+3×16/3 | 196/0.40 | (76-81)×(33-35) | 0.78 | 0.795 | 4300 | |
| 3×35+3×16/3 | 276/0.40 | (79-84)×(34-36) | 0.554 | 0.565 | 4800 | |
| GKFB-6KV | 3×16+3×16/3 | 126/0.04 | (62-64)×(27-28) | 1.21 | 1.24 | 2815 |
| 3×25+3×16/3 | 196/0.40 | (66-69)×(29-31) | 0.78 | 0.795 | 4100 | |
| 3×35+3×16/3 | 276/0.40 | (70-73)×(30-33) | 0.554 | 0.565 | 4750 | |
| 3×50+3×16/3 | 396/0.40 | (76-79)×(32-35) | 0.386 | 0.393 | 6300 | |
| 3×70+3×25/3 | 360/0.50 | (82-85)×(34-37) | 0.272 | 0.277 | 7380 | |
| 3×95+3×35/3 | 475/0.50 | (88-92)×(36-39) | 0.206 | 0.21 | 7800 | |
| 3×120+3×35/3 | 608/0.50 | (96.5-100)×(39-41) | 0.161 | 0.164 | 9500 | |
Packing Material: Coil (For small size & short length) , Wooden Drum , Iron-Wooden Drum , Steel Drum
Shipping: Loading port from Qingdao or Shanghai , 12-24 hours from facotry to sea port
|
|
